مادربرد ایسوس H81M-E استوک

مادربرد ایسوس Motherboard Asus H81M-E

Graphic
Integrated Graphics Processor
Multi-VGA output support : DVI/RGB ports
Supports DVI with max. resolution 1920 x 1200  60 Hz
Supports RGB with max. resolution 1920 x 1200  60 Hz
Maximum shared memory of 1024 MB
Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider
Memory
2 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Due to Intel chipset limitation, DDR3 1600 MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600 Mhz.
USB Ports
Intel H81 chipset :
2 x USB 3.0/2.0 port (2 at back panel, blue)
Intel H81 chipset :
8 x USB 2.0 port (4 at back panel, black, 4 at mid-board)
LAN
Realtek 8111G, 1 x Gigabit LAN Controller
Audio
Realtek ALC887 8-Channel High Definition Audio CODEC 2
Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
CPU
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
Supports Intel 22 nm CPU
Supports Intel Turbo Boost Technology 2.0
The Intel Turbo Boost Technology 2.0 support depends on the CPU types.
Expansion Slots
1 x PCIe x16
2 x PCIe 2.0 x1
Storage
Intel H81 chipset :
2 x SATA 6Gb/s port, yellow
2 x SATA 3Gb/s port, dark brown
